Cold Transfer Product - Metallic
Sheet-Fed
CTSB-Grade
Cold transfer product for sheet-fed offset presses
CTSB is a cold transfer product designed for use in combination with offset adhesives and inks for applications such as commercial print, label print and luxury packaging.
Key Features
The CTSB grade is a free releasing transfer product with good adhesion onto offset cold transfer adhesives, both UV curing and conventional drying. It has a very receptive surface facilitating in-line or off-line over-printing with UV curing and conventional drying offset inks, so providing the opportunity to create a wide spectrum of eye-catching, multi-coloured metallic effects. Good fine detail, solid area coverage and high brilliance or gloss.
Key specifications for cold transfer
Machine: Designed for use on sheet-fed offset presses equipped with a cold transfer module. Suppliers include Heidelberg, manroland, Compact Foilers, Eagle Systems, Foiltone and Vinfoil.
Adhesive: Good adhesion onto many UV curing and conventional drying cold transfer adhesives. Suppliers include Zeller + Gmelin, Jänecke + Schneemann, Huber, Flint, INX, and Toyo, as well as Heidelberg and manroland. Optimized application quantity: 1.2-2.2 g/m².
Inks: Allows good adhesion of UV curing and conventional drying inks and coatings. Contact suppliers of cold transfer adhesives, inks and coatings for recommendations and further information or contact the Customer Service Team at API Transfer Technologies.
Substrates
Coated papers and boards as well as recycled stocks and structured label papers. Suitability of the substrate for cold transfer should be confirmed by the customer.
Formats
Maximum roll length: 20,000m. Various roll sizes available – please inquire!
Availability
For information on stock availability, contact the Customer Service Team at API Transfer Technologies.
You can find the colour options currently available from stock for this grade along with a link to our 3D Colour Gallery for further information at the bottom of this page.
Storage
The product should not be stored or transported in direct sunlight, and should avoid extremes of heat and humidity, as well as condensation and undue pressure on the roll. Under ideal storage conditions of 5-25°C and 30-60% relative humidity, a storage life of 12 months should be possible.
Typical market sectors
- Wines & Spirits
- Cosmetics & Perfumery
- Food & Confectionery
- Personal Care
- FMCG
Datasheet
Data contained in this information sheet is provided as a source of information that we believe to be accurate and reliable at time of writing but does not constitute a warranty of any kind. Customers should determine to their own satisfaction the suitability of this material for a specific purpose. API Transfer Technologies reserves the right to change specifications without notice. Please contact the Customer Service Team at API Transfer Technologies for further information and availability details. Samples are available from us upon request. If you need assistance, we will be happy to provide advice and support.
Available Colours
Please note that we only list the grades we have available from stock here. Many colours can also be ordered in further grades on special request and with the appropriate order quantity. If the colour you require is not listed here in the grade you need, please contact us by telephone or using the contact form below to ask us about further options.
The colours displayed on your screen are very close to the exact product colour, but are still only digital representations of the original colours. The device you are viewing this on may cause the colour to appear different. We strongly recommend that you request a sample to get an accurate representation of the colour.
