OXN-Grade

Universal hot stamping transfer product for fine to medium detailed stamping designs

OXN is a universal metallic transfer product for fine to medium detailed stamping designs, well-established in the hot stamping market.

Key Features

The OXN grade is designed for fine to medium definitions, delivering outstanding results with high stamping speeds and a high-gloss finish. It offers excellent abrasion and scratch resistance, ensuring durability and quality. OXN is suitable for a wide range of materials, including various types of paper, printed and lacquered substrates, and OPP laminates. It is also highly versatile, working seamlessly with nearly all machine types in the graphic industry.

Key specifications for hot stamping

Designed for use on a wide range of hot stamping machines, with typical operating temperatures:

Vertical, platen and clam-shell machines: 90℃ - 145℃

Cylinder machines: 130℃ - 165℃

Rotary machines: 210℃ - 245℃

The optimum stamping temperature is dependent upon machine type and other application parameters, and the customer should determine to their own satisfaction the suitability of the foil application and press setup.

Substrates

Plain paper and board, printed paper and board, coated and mat paper, lacquered substrates, OPP laminates.

Availability

For information on availability, contact the Customer Service Team at API Transfer Technologies.

Storage

Foils should not be stored or transported in direct sunlight, and should avoid extremes of heat and humidity, as well as condensation and undue pressure on the roll. Under ideal storage conditions of 5-25°C and 30-60% relative humidity, a storage life of 12 months should be possible.

Typical market sectors

Labels (sheetfed and rotary)
General packaging applications (cosmetics, cigarettes, food and confectionary)

Data sheet

API_Transfer_TDS_OXN_ENG.pdf (111.4 KiB)

Data contained in this information sheet is provided as a source of information that we believe to be accurate and reliable at time of writing but does not constitute a warranty of any kind. Customers should determine to their own satisfaction the suitability of this material for a specific purpose. API Transfer Technologies reserves the right to change specifications without notice. Please contact the Customer Service Team at API Transfer Technologies for further information and availability details. Samples are available from us upon request. If you need assistance, we will be happy to provide advice and support.

Available Colours

Please note that we only list the grades we have available from stock here. Many colours can also be ordered in further grades on special request and with the appropriate order quantity. If the colour you require is not listed here in the grade you need, please contact us by telephone or using the contact form below to ask us about further options.

The colours displayed on your screen are very close to the exact product colour, but are still only digital representations of the original colours. The device you are viewing this on may cause the colour to appear different. We strongly recommend that you request a sample to get an accurate representation of the colour.

Contact us

Would you like to see and inspect the selected grade sample live? We have already pre-filled our contact form for you with the current selected product grade. Simply enter your contact details and submit the form and we will be happy to send you samples for this grade.
