Hot Transfer Product - Metallic
Versatile Graphical
GHN-Grade
Universal metallic hot stamping transfer product for fine to medium detailed stamping designs
GHN is a universal metallic transfer product for fine to medium detailed stamping designs, well-established in the hot stamping market.
Key Features
The GHN grade is perfect for fine to medium definitions, offering a high-gloss finish and exceptional versatility. It is well-suited for use on dry, uncoated paper, coated paper, and even laminated paper. GHN supports hot stamping and embossing in a single pass, streamlining production processes. Additionally, it is compatible with nearly all machine types in the graphic industry, making it a reliable and flexible choice.
Key specifications for hot stamping
Designed for use on a wide range of hot stamping machines, with typical operating temperatures:
Vertical, platen and clam-shell machines: 100°C - 120°C
Cylinder machines: 130℃ - 180℃
Rotary machines: 170℃ - 230℃
The optimum stamping temperature is dependent upon machine type and other application parameters, and the customer should determine to their own satisfaction the suitability of the foil application and press setup.
Substrates
Coated, unprinted & printed papers and cartons, self-adhesive label materials, OPP/PET laminated papers and cartons, self-adhesive films.
Availability
For information on availability, contact the Customer Service Team at API Transfer Technologies.
Storage
Foils should not be stored or transported in direct sunlight, and should avoid extremes of heat and humidity, as well as condensation and undue pressure on the roll. Under ideal storage conditions of 5-25°C and 30-60% relative humidity, a storage life of 12 months should be possible.
Typical market sectors
- Packaging for the food and cosmetic industry
- Greeting cards
- Flexible plastics
- Book covers
- Labels
- General hot stamping applications
Data sheet
Data contained in this information sheet is provided as a source of information that we believe to be accurate and reliable at time of writing but does not constitute a warranty of any kind. Customers should determine to their own satisfaction the suitability of this material for a specific purpose. API Transfer Technologies reserves the right to change specifications without notice. Please contact the Customer Service Team at API Transfer Technologies for further information and availability details. Samples are available from us upon request. If you need assistance, we will be happy to provide advice and support.
Available Colours
Please note that we only list the grades we have available from stock here. Many colours can also be ordered in further grades on special request and with the appropriate order quantity. If the colour you require is not listed here in the grade you need, please contact us by telephone or using the contact form below to ask us about further options.
The colours displayed on your screen are very close to the exact product colour, but are still only digital representations of the original colours. The device you are viewing this on may cause the colour to appear different. We strongly recommend that you request a sample to get an accurate representation of the colour.
